SYSTEM SPECIFICATIONS
Speaker type Full range
Max. Power 20 W
RMS Power 10 W
Impedance 8 Ω (CELO2)
16 Ω (CELO2D)
Sensitivity (1W/1m) 83 dB
Sound Pressure (Max. W/1m) 93 dB
Connectors Gold-Con™ spring clamps
Drivers 2” Aluminium membrane
Frequency Response (± 3 dB) 120 Hz - 20 kHz
Range (-10 dB) 100 Hz - 20 kHz
Dispersion Conical 165°
PRODUCT FEATURES
Dimensions 118 x 98 mm (Ø x D)
Weight 0.350 kg
Construction ABS
Front finish Thin edged white grill (RAL9003)
Cut-out measurement 100 mm (Ø)
Built-in depth 95 mm
Mounting & handling 2 Screw quick-fixing mechanism
Operating temperature -20 °C ~ 60 °C
Colours Black frame & white grill
Accessories Included Cut-out template
GLC02/W - White grill (RAL9003)
Optional WTR06 - 6W 100V line transformer
GLC02/B - Black grill (RAL9005)
GLC02/P - Paintable grill
