dB Technologies DVA-S09 Dp Aktif 15 inç 1000W Rms Band-pass Subwoofer
Technical Data
Speaker TypeActive Bandpass Subwoofer
Acoustical data
Frequency Response [+/- 3dB]45 - 120 Hz
Max SPL134 dB
DirectivityOmnidirectional
LF15 "
Voice Coil LF4 "
Amplifier
Amp TechnologyDigipro®
Amp ClassClass D
LF Amp1000 W RMS
CoolingConvection
Processor
ControllerAnalog (Stereo)
Phase0, 180 °
LimiterRMS, Peak, Thermal
Delay OptionNO
Crossover Frequency LF-MF90, 120 Hz
LF-Xover out slope24 dB/Octave
Mechanics
HousingMultiplex plywood
Housing DesignRectangular
ColorBlack, White
Handles2x Side
Pole Mount1x M20
Rigging Points2xPick Points on top to fix
DRK10/20 rigging frames
AccessoryWheels 100mm, Dust Cover, Rain Cover
Width515 mm (20.6 in)
Height440 mm (17.6 in)
Depth720 mm (28.8 in)
Weight37.5 kg (82.67 lbs)
