dB Technologies LVX-12 12 inch 1600W Peak Aktif Kabin
Technical Data
Speaker Type 2-Way Active Speaker
Acoustical data
Frequency Response [-10dB]55 - 20.000 Hz
Frequency Response [-6dB]62 - 19.000 Hz
Max SPL127 dB
HF1"
Directivity90 x 40°
HornRotatable CD Horn
LF12"
Amplifier
Amp TechnologyDigipro® G2
Amp ClassClass-D
Peak Power1600 W
PRG Power800 W
Processor
ControllerDSP 24bit/48kHz
System PresetsFlat, Processed
LimiterDual Active Peak, RMS, Thermal
Crossover Frequency LF-HF1800 Hz
Slope LF-HF24 dB/Octave
Mechanics
HousingMultiplex
Angles UpMonitor use 45°
Handles3 (1x top side, 1x side)
Rigging points12 x M10
Pole MountD36 mm
Width360 mm (14.17 in)
Height610 mm (24 in)
Depth360 mm (14.17 in)
Weight17 kg (37.5 lbs)
